$1,000.00
Characteristics:
The wholevehicle is simple,dexterous, reliable andeasy to operate, lt has a compact structure,smallturning radius and it’s suitable for operation in anarrow space.
The vehicle iscompact and reliable,equippedwitha full protective metal housing.
Portable lithium electric bag, easy to open the coverand replace the battery.
Standard equipped with emergency stop switchand emergency reverse device to ensure safe use
With poweroff brake function, when release handleor press bottom, the vehicle immediately poweroff brake.
The dual protection ofelectromagnetic brakingand motorbraking is used to ensure the safety ofdriving.
Environmental Friendly
– The emission meets EC and EPA new regulation.
– High efficiency hydraulic system to lower the fuel consumption.
– Using environmental friendly material.
– Damping device on the mast to reduce impact and vibration.
– Sound insulating and absorbing device are used to reduce the noise.
Ergonomics design
– Using power braking system to reduce footplate strength.
– Control lever right located to effectively reduce drivers arm tiredness.
– Dual combined switch lever as a car to enable easy operating.
– Wide mast with good visibility.
– Wide space for boarding and driving , increasing leg space.
– Engine automatic monitor control, when the engine oil pressure is too low or water temperature is too high, the engine will be automatically shut off.
Safety performance
– Enclose cabin is made of assembling steel plate, high strength overhead is designed to ensure the safety.
– Parking brake with safety protection device, when parking brake is working, the forklift will not move even the direction lever is turned.
– Safety device in mast hydraulic system prevents material falling down in case of hose broken.
– High pressure hose is designed far away from the driver.
– Safety wire harness, using waterproof plug
Product Model / CDD15Y CDD 20Y
Drive type / Electric
Driving Style / Stand-and-drive type
Load Capacity kg 1500 2000
Load centre mm 500
wheelbase mm 1383
tyre / Polyurethane wheels
Drive wheel size (diameter*width) mm φ210*70 φ250*80
Front wheel size (diameter*width) mm φ80*70
Balance wheel size(diameter*width) mm φ125*50 φ125*40
Front Wheelbase mm 500
Rear wheelbase mm 616
Overall height（Min height） mm 2080/1580/1830/2080/2330
lift height mm 1600/2000/2500/3000/3500
Min height mm ≤90
Operating handle height above ground (max/min) mm 1520/1050
Overall Length （stand up/down） mm 2023/2419 2030/2419
Overall Width mm 852 850
Fork size mm 170/55/1150
Outer width of fork mm 680
Min height mm 30
Turning radius（Pedal up） mm 1619
Travel speed (empty /no load) km/h 4/5
Max. climbing ability（no load） mm/s 100
Max. climbing ability（empty load） mm/s 50
Max. climbing ability（empty /no load） % 3/5
service brake / Electromagnetic brake
Drive motor rating kw DC0.75 DC1.5
Lifting motor rating kw DC2.2
Battery voltage/rated capacity a/ah 2*12v/120ah
